92X92X25 AC AXIAL FAN 230VAC, COMMONWEALTH 0.68M3/MIN, 2300RPM

92252abtl ventola assiale 230v 92x92x25 commonwealth 2300rpm

92X92X25 AC AXIAL FAN 230VAC, COMMONWEALTH 0.68M3/MIN, 2300RPM

21.78 Iva esclusa

In stock

Size: 92x92x25
Voltage: 230VAC
Bearing System: ball
Terminal: Faston
Material: UL94 V-0
Life: 40.000h at 25°C
Working temperature: -10 ° C / + 70 ° C
Certification: CE

Chiama per assistenza 039 6250932

21.78 Iva esclusa

Codice Produttore: FP-108B 230V S3BT
Availability: 18 in stock SKU: 92252ABTL Categories: ,
Marca:
View cart
Unità
Scontistica per unità
1-4
€ 17.51
5-14
€ 16.64
15-20
€ 15.80
+20
Richiedi prezzo speciale

Description

Compact AC axial fans have always found great application for cooling in the electronics sector and are used for both cooling and suction in applications ranging from refrigerated display cases, to electrical panels or racks.

The compact design allows installation even in the most confined spaces such as in electrical panels or fireplaces (axial fans in metal resistant to high temperatures).
Accessories such as filters, grids or fasteners are also available
RoHS compliance

Size (mm)
92x92x25
Voltage (V)
230V AC
Bearing System
Ball
Terminals
Faston
Current (A)
0.04
Power (W)
5.5
Speed (rpm)
2300
Max air flow (m3/min)
0.68
Max air flow (CFM)
24
Max pressure (InH2O)
0.13
Max pressure (mmH2O)
3.301
Noise (db/A)
23
Weight (gr)
230
